PoE Injector-Passive

PJ48M-19W Passive（100Mpbs, 19W)

Product description: Passive Single-Port PoE Injector PoE standards: Non-standard Power Pin: 4/5(+)7/8(-)
INQUIRY

Product Details:

Model Number:	PJ48M-19W passive	Ports:	1xPoE + 1xUplink
Min. Order Qty:	1 PCS	Trade Term	EX WORKS, FOB, CIF…
Products Status:	Make-to-Order/Stock	Delivery Time:	1-30 days
Certification:	CE, FCC, ROHS	Warranty	1 year

The PJ48M-19W passive injector is a Power over Ethernet Injector with one Ethernet Input (data only) port and one Output (data + power) port that is designed for small or medium network environments. This product can convert standard 100~240VAC power into low voltage DC that runs over existing LAN cable to power up the network device with PoE function directly.

Key Features:

- Up to 19W Power (compatible with standard PoE Injector PJ803 with IEE802.3af)

- Minimize the need for a bulky power adapter and power line
- Delivering power and data to equipment via a single Ethernet cable

- High safety with surge protection
- Remote power feeding up to 100 meters
- PnP, Light Weight and compact size
- Supports 10/100Base-T LAN environment
- Unique interlocking feature for easy installation

Caution: directly power output on PDs Passive "always on" power

Technical Specification:

Standards	Non-standard
PoE Performance	Power Input: AC 100V-220V～50-60HZ PoE Power Output: 48~56V/19W Power Pin Assignment: 4/5(+)7/8(-), Mode-B, End-Span
Transmission Media	10Base-T: 3, 4, 5 types of unshielded twisted pair (≤ 100m) 100Base TX: Category 5 and above unshielded twisted pair (≤ 100m)
LED Indicators	Power/PoE Status
Network Interface	1PoE Port at 10/100Mbps 1Uplink Port at 10/100Mbps
Dimension/weight	55125210mm/ 400g 40pcs/carton, carton size: 580435277 16kg
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Certifications	CE/FCC/ROHS
