POE-S4G-1GUPL

Product description: 4-Ports PoE 10/100/1000Mbps TP+ 1-Port 10/100/1000Mbps Up-link PoE Switch
INQUIRY

Product Details:

Key Features:

-Up to 15.4W/25.4W of Power on

-IEEE 802.3at Compliant with 2-event classification

-Safe: Low Power Devices Receive Only the Power They Need

-Safe and Reliable Power to WLAN Access Points

-Automatic Detection and Protection of Non–standard Ethernet Terminals

-Compact Design Fits Easily in WLAN Access

-Ethernet Terminals

-Supports 10/100 /1000Base-T applications

-Plug-and-Play no configuration required

-Internal power supply

-Easy installation and maintenance

Technical Specification:

Standards	IEEE 802.3 10-BASE-T IEEE 802.3u 100-BASE-TX IEEE 802.3ab 1000-BASE-T IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3at IEEE 802.3af
PoE Performance	PoE Standard: IEEE 802.3af/at Power over Ethernet PoE over current protection PoE circuit sorting protection PoE Power Output: Per Port 54V DC, 600MA, Max. 30 watts Power Consumption: 65 Watts(Max) PoE Power Budget: 60 Watts PoE port priority: support Storage and forward: support Switch Fabric: 10Gbps MAC Address Table: 2K
Transmission Media	10Base-T: 3, 4, 5 types of unshielded twisted pair (≤ 100m) 100base TX: Category 5 and above unshielded twisted pair (≤ 100m) 1000BASE-T: unshielded twisted pair of cat 5 and above (≤ 100m)
LED Indicators	Port: PoE in use(Green), Power:Orange
Network Interface	4x 10/100/1000Mbps RJ-45 (PoE 2~5 Ports) Auto-MDI/MDI-X 1x 10/100/1000Mbps RJ-45 Uplink
Power Input	Input: 100~240V/AC, 50~60 Hz, Internal Power Supply
Power Consumption	65 Watts(Max)
Dimensions: (L x W x H)	185 x 118 x 44 mm / 800g
Temperature	Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Certifications	CE/FCC/ROHS
