Product Details:
|
Model Number: |
POE-S4M-1MUPL |
Ports: |
4FE PoE + 1FE Uplink |
|
Min. Order Qty: |
1 PCS |
Trade Term |
EX WORKS, FOB, CIF… |
|
Products Status: |
Make-to-Order/Stock |
Delivery Time: |
1-30 days |
|
Certification: |
CE, FCC, ROHS |
Warranty |
3 Years |
Key Features:
- Up to 15.4W/25.4W of Power on
- IEEE 802.3af Compliant with 2-event classification
- Safe: Low Power Devices Receive Only the Power They Need
- Safe and Reliable Power to WLAN Access Points
- Automatic Detection and Protection of Non–standard Ethernet Terminals
- Compact Design Fits Easily in WLAN Access
- Ethernet Terminals
- Supports 10/100 Base-T applications
- Plug-and-Play no configuration required
- Internal power supply
-Easy installation and maintenance
Technical Specification:
|
Standards |
IEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet |
|
|
PoE Performance |
PoE Standard: IEEE 802.3af/at Power over Ethernet / PSE PD classification identity PoE over current protection PoE circuit sorting protection PoE Power Output: Per Port 48V DC, Max. 30watts Power Pin Assignment: 1/2(+), 3/6(-)
Switch Capacity: 1.0Gbps; Throughput: 0.1448Mpps
MAC Address Table: 2K; Memory
Buffer: 448k
|
|
|
Transmission Media |
10 BaseT Cat 3,4,5 UTP/STP 100M BaseTx CAT 5 UTP/STP |
|
|
LED Indicators |
Per Port: PoE in use(Orange), 10/100 Link/Act(Green) Green: Power |
|
|
Network Interface |
4 x 10/100Mbps RJ-45 (PoE 2~5 Ports) 1x 10/100Mbps RJ-45 Uplink |
|
|
Power Input |
Input: 100~240V/AC, 50~60 Hz, 2A Internal Power Supply |
|
|
Power Consumption |
65Watts(Max) |
|
|
Dimensions/weight |
185 x 118 x 44 mm / 800g |
|
|
Temperature |
Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
|
|
Certifications |
CE/FCC/ROHS |
